HUADA/HAWKER鋰電池EV48-80/霍克AGV蓄電池

　　Introduction



　　Hawker HuaDa EV series of power battery,is the international advanced level of lithium iron phosphate(LiFePO4)power battery system.With high energy density,long cycle life,excellent charge and discharge performance,good temperature performance,is a new generation of high security and high reliability of the green power supply.



　　This series of batteries is the use of the latest development of the battery management system(BMS),specifically for mobile mechanical equipment,online charging and wireless charging and design and production of power batteries,with advanced battery self-management,communication,alarm and short-term fast charge Complete function.



　　Product Features



　　●Excellent charge and discharge overvoltage and undervoltage protection



　　●provide analog output AO,SOC analog output 0~5V,user-friendly power monitoring



　　Note:SOC can only be used as a reference,can not be used as a decision.



　　●Provides a highly efficient passive equalization system



　　●Charge/discharge are all with short circuit insurance



　　●Panel LED power,system status display



　　●Rich interface,through the digital IO and 485 interface to achieve information exchange



　　●professional industrial design and material selection,sustainable work in the harsh industrial environment



　　●support high-power charge and discharge,to meet the needs of a variety of different industrial conditions



　　●wide temperature working environment conditions,-20 degrees-60 degrees



　　●small size



　　Dimensions specifications



　　Types



　　Battery size



　　Long*wide*high（mm）



　　Charge continuous current



　　Discharge continuous current



　　EV24-40



　　315*237*165mm



　　80A



　　20A



　　EV24-60



　　315*240*215mm



　　320*237*188mm



　　460*220*150mm



　　120A



　　30A



　　EV24-80



　　355*330*215mm



　　160A



　　40A



　　EV24-100



　　355*330*215mm



　　200A



　　50A



　　EV24-120



　　400*275*245mm



　　180A



　　60A



　　EV24-200



　　550*210*425mm



　　200A



　　100A



　　EV48-30



　　345*238*200mm



　　60A



　　30A



　　EV48-60



　　590*240*240mm



　　120A



　　30A



　　EV48-80



　　585*345*230mm



　　160A



　　40A



　　EV48-100



　　585*345*230mm



　　200A



　　50A



　　EV48-160



　　605*435*255mm



　　160A



　　80A



　　EV48-200



　　615*650*250mm



　　160A



　　100A



　　EV48-250



　　605*290*480mm



　　200A



　　125 A



　　Performance specifications



　　project



　　Features



　　Overvoltage protection



　　3.7V(single string)



　　Undervoltage protection



　　2.8V(single string)



　　Charging parameters



　　Maximum 2C lasts for 10 minutes,1C continues



　　Discharge parameters



　　Up to 1C continuous



　　Charge and discharge port form



　　Charge and discharge



　　fuse



　　Have



　　RS-485 communication



　　Have



　　Analog output AO



　　Have



　　Configurable DO output



　　Have



　　Power LED display



　　Have



　　Master switch



　　Have



　　Operating temperature



　　-20℃~60℃



　　Storage temperature



　　-20℃~70℃



　　Working humidity



　　Relative humidity of 10%to 80%,no condensation



　　cooling system



　　Passive natural cooling



　　Charger requirements



　　Lithium iron phosphate battery charger



　　Battery shell color



　　Toyota White(customizable)
